ROBOT LAWN MOWER

Segway Navimow H230

Triple fusion system:

Network RTK + LiDAR

high resolution

solid state + Vision for

absolute precision and reliability.

Cutting-edge LiDAR technology

analyzes space at nearly 200,000 points

to the second, meticulously creating

an ultra-dense 3D point cloud

that leaves no uncovered areas. Every little

detail is captured for a

constant navigation day after day.

Thanks to LiDAR technology

high resolution and vision, H2

transform every corner of the garden

in a real interactive map

directly to your phone.

View, edit and control your

robot lawnmower with

unparalleled precision.

Drag and drop to customize

your boundaries at their best.

The H2 Series redefines

navigation with a cleverly designed system

integrated: spatial awareness

of LiDAR, the satellite precision of the

RTK network and improved support

of the vision merge. The turning point?

Change positioning mode

easily in just 1ms (faster than

how fast you can blink)

for uncompromising performance.

With the technology of adaptation to the

3D terrain, complex lawns are

divided into optimal work zones,

choosing mowing paths

especially efficient for slopes.

Paired with a new system

ESC (Electronic Stability Control)

stability), H2 regulates precisely

the speed of the wheels during the

curves to optimize the center of gravity of the

lawnmower, tackling slopes of the

45% (24 degrees) with absolute stability.

No slipping, no

effort, only impeccable cuts with

naturalness.

Unmatched durability proven by

over 60 rigorous reliability tests

and resistance to shock and vibration

50G, setting a new benchmark

reference that far exceeds

industry standards. Absorbs shock

and falling objects, maintaining

consistent performance over time.

No cables, no antennas and

flexible location of the charging station

thanks to our latest system

navigation based on LiDAR technology.

Take it out of the box, plug it in, press “start”

and is immediately ready for use. It gives you back

time, freedom, and a perfect lawn without the hassle.

Voice control via Alexa

and Google Home. Garden care

It's never been so easy!

The rain sensor and forecasts

integrated weather forecasts maintain the

your H2 one step ahead. When it detects

heavy rain, snow, frost, strong wind

or extreme heat, stops mowing

and automatically returns to base.

TECHNICAL SPECIFICATIONS

Recommended mowing area: 3000 m2

Dimensions: 624x445x295 mm

Net weight: 16.25 kg

Location system: EFLSTM LiDAR + (LiDAR+NRTK+Vision)

Object Detection System: VisionFenceTM (140° RGB Camera + LiDAR)

Drive motor: Rear-wheel drive

Noise level: 60 dB (A)

Protection level: IP66

Weather Adaptation: Weather Forecast + Rain Sensor

Maximum slope ability: 45% (24 degrees)

Automatic mapping: Yes

Automatic recharge: Yes

Vertical clearance: 3 cm

Multi-zone management: 30

GeoSketchTM: Yes

Battery capacity: 10 Ah

Charging time: 120 minutes

Continuous mowing area per day: 3800 m2 / 24 hours

Cutting height: 2 - 7 cm

Manual cutting height adjustment: Auto

Cutting width: 22 cm

Cutting deck with blade protection: Yes

Cutting disc: 1 disc, 6 blades

GPS Tracking: Yes

Out of border alert: Yes

Lift Alarm: Yes

Proximity unlock: Yes

Where is it: Yes

Object Recognition: Over 200

Warranty: Device: 3 years / Battery: 2 years

Smart Home Integration: Alexa and Google Home

Connectivity: Bluetooth, Wi-Fi, and cellular*

Display: 2.4" LCD screen

OTA Updates: Yes

*Connect+ (cellular connection: 1 year free)

for all H2 models, renewable annually

CODE:887080
