SILENT GENERATOR

ZANETTI ZBG11003 SEA



The ZBG 11003 SEA from Zanetti's Full Power range

It is designed to ensure power

reliable in both single-phase and three-phase.

Designed with an eye-catching and modern design,

This generator delivers high performance in a quiet manner.

The model is equipped with AVR and ATS for starting

automatic, ensuring continuity even in the event of a blackout.

With the easy-to-open top door,

maintenance is simplified.

Designed for those seeking reliability and style,

The ZBG 11003 SEA is a complete professional solution

for every energy need.



SPECIFICATIONS

Type: Single-phase/Three-phase

Maximum power (kW max 5 minutes): 11 (400V) / 9.5 (230V)

Continuous power (kW): 10 (400V) / 9 (230V)

Voltage (V): 230/400

Frequency (Hz): 50

Continuous output current (V/A): 12/8.3

Tank capacity (Lt): 27

Autonomy at 50% (h): 7

Wheel kit: Yes

Battery: Yes

Dry weight (Kg): 225

Dimensions mm (LxWxH): 1255x775x1100

Socket Type: 1x16A/220V + 1 x 32A/220V + 1x16A/380V

Engine type: 680/2

Engine displacement (cc): 679

Engine power Kw: 14.5

Engine speed (rpm): 3900

Engine cooling: Air

Engine start: Electric

Voltage regulator: AVR

IP protection rating: IP23M

V.F.R.T. – Voltometer, Frequency, Run Time, Total Time: Yes

Oil alarm device: Yes

Automatic control unit ATS pred.: Yes

Fuel gauge: Yes

Differential circuit breaker: No

Frame: Silenced



CODE:ZBG 11003 SEA
