BATTERY-POWERED DRILL

STIHL BTA 140



With 3 working modes

for professional use



With the STIHL BTA 140 cordless drill

of the STIHL AP system

you can make holes in the ground up to 300

mm in diameter. It is the ideal solution for

professional applications in

gardening and greenery care,

in agriculture, forestry and construction.

It allows you to install poles in a

quick and efficient, digging holes for plants

and drainage wells or build foundations

small and medium sized. The sharp tips and the

spirals with cutting blades penetrate

effective even on stony terrain.



The powerful, virtually frictionless EC motor

from maintenance, ensures proper functioning

smooth with reduced vibrations. Furthermore, thanks to its

silence, you can work without

the use of hearing protection.



The STIHL BTA 140 cordless drill is designed

for use by a single operator.

The excellent balance and the drilling axis close to the

body ensure ergonomic use,

comfortable and with less fatigue.

The drill has 3 working modes: slow, for operations

simple with reduced backlash;

fast, to tackle more challenging terrain;

and reverse, to easily release the tip in case of

locking. The selected mode can

be set directly from the handle

of command and is displayed on the integrated display.



The wide padded support, designed

to fit comfortably on the body,

allows you to guide the drill with precision and stability. In case of

locking during work, the STIHL system

QuickStop automatically detects rotation

sudden stop of the tool and immediately interrupts the

drilling. You just need to reactivate the device via

the handle to get back to work immediately.

Furthermore, thanks to the intelligent support for the

transport, you can store the drill

in a compact way, while protecting at the same time

the QuickStop system from impacts.



To get the best performance

with the STIHL BTA 140 cordless drill, STIHL

recommends using the STIHL AP 300.0 P battery.



Note: STIHL AP system tools

can be used with both batteries

ALLPRO both with AP batteries.



TECHNICAL DATA

Rated voltage: 36 V

Max voltage: 40 V

Power consumption: 2.10 kW

Power: 1.70 kW

Battery system: ALLPRO/AP

Recommended battery: AP 300.0 P

2nd gear spindle: 230 rpm

Spindle reverse gear: 35 U/min

Device weight: 7.6 kg

Minimum number of holes per AP 200 S battery charge: 100

Maximum number of holes per AP 200 S battery charge: 150

Minimum number of holes per AP 300 S battery charge: 150

Maximum number of holes per AP 300 S battery charge: 230

Minimum number of holes per AP 500 S battery charge: 180

Maximum number of holes per AP 500 S battery charge: 270

Hole diameter with "Minimum number of holes per battery charge": 150 mm

Hole diameter with "Maximum number of holes per battery charge": 90 mm

Device Width: 375 mm

Device height: 285 mm

Device length: 555 mm



WITHOUT BATTERY

AND BATTERY CHARGER





CODE:UA01-011-9200

UA010119200
