EVOLUTION 2.4 MULTI-FUNCTION Hedge Trimmers Robust, lightweight and versatile brushcutter for smallholders who want to keep their garden in shape. Its quiet operation makes it particularly suitable for residential areas. Also equipped with the EASY START system to easily start your brushcutter and get you up and running right away. TECHNICAL DATA - ENGINE SPECIFICATIONS: Type: Active 2-stroke Displacement: 24.5 CC Power (hp / kW): 1.4/1.03 Carburetor: Walbro WYC Ignition: Digital Air Filter: Single - DIMENSIONS AND WEIGHT: Rod diameter (Ø mm): 26 Thickness rod (mm): 1.5 Weight handle (Kg): 5. 3 Reservoir capacity (Lt.): 0.5 - OTHER CHARACTERISTICS: Clutch (Ø mm): 54 FITTING: Head 120 10x1.25 sx. f. Belt: mod. Easy Grass Disc CHARACTERISTICS - Carburettor Walbro carburettor with first-rate diaphragm with primer for immediate ignition. Mylar diaphragms resist unleaded petrol even with a high percentage of alcohol and alkylated petrol, maintaining flexibility over time. - Clutch Professional clutch with pads made of special material oversized by 54 mm. Maximum resistance to stress and transmission of all motor energy to the cutting tool without loss of power. - Quick-release coupling With safety pin for quick and easy changing of cutting attachments while maintaining optimum attachment of cutting attachments. - Transmission Special alloy tube, light and resistant to bending with 6 self-lubricating anti-vibration bushings (unique feature on the market), maximum smoothness of shaft movement and maximum operator comfort. - Transparent fuel tank for an immediate check of the fuel level, new wider and sturdier cap ensuring comfortable use and a perfect seal. RUBBER and PIPPETS made of Viton, a material resistant to unleaded petrol and high temperatures. EXHAUST designed to avoid the Vapor - Lock phenomenon. - Muffler With special silencer machined inside, superior engine performance and maximum noise and vibration reduction. Equipped with a non-deformable graphite exhaust gasket resistant to heat up to 900 C. - Crankshaft Made of case-hardened steel, equipped with silver-plated roller cage for racing engines in large displacements. Hyper-lightweight piston for minimum vibration with 2 special cast iron piston rings for superior durability. Engine designed for high torque even at low revs. - Oil-bath sponge filter, which on the larger models is double-layered. This filter allows excellent performance and reduced maintenance costs. Paper filter optional on 4.5-5.5 engines. - Highly robust bevel gear with upper flange with three labyrinths for protection. Designed to optimally transfer power to the cutting device and withstand frequent blows during operation. ACTIVE Original part number: 124EV04 CZ
